HAITUN Remotely Operated Vehicle(ROV)

Product introduction

The "HaiTun" series is an observation and light work class remotely operatedvehicle (ROV) developed by Deepinfar.Ltd. The “HaiTun” weighs 100 ~ 600kgand is suitable for working in a wide water environment. Compared with othersmall underwater vehicles, it has a strong payload capacity and is lessaffected by currents and waves. The high stability and flexibility of "HaiTun"makes it suitable for offshore applications.

Application Field

Sunken Vessel Salvage
Maritime Research
Offshore WindPower
Submarine Exploration

Parameters

Product introduction

The "HaiTun" series is an observation and light work class remotely operatedvehicle (ROV) developed by Deepinfar.Ltd. The “HaiTun” weighs 100 ~ 600kgand is suitable for working in a wide water environment. Compared with othersmall underwater vehicles, it has a strong payload capacity and is lessaffected by currents and waves. The high stability and flexibility of "HaiTun"makes it suitable for offshore applications.

Application Field

Sunken Vessel Salvage
Maritime Research
Offshore WindPower
Submarine Exploration

Product advantag
Technical parame

	Unrivalled Stability		Multiple payloads
	4 horizontal +4 vertical thrusterconfiguration to achieve 6 degrees of freedom Built-in fiber optic gyro, free from magnetic field interference, drift <0.1 ° / h, especially suitable for fine operations in complex sea environment Dynamic positioning system, adjust the thruster to offset the position deviation caused by external force, suitable for harsh sea state		Open frame structure, with 12.5~50kg payload
	Designed for fine work
	Accessories include 2 manipulators (5 function+2 function or 5 function+5 function), vortex generator, drilling tool, sampling tool, cutting tool etc.

	“HaiTun”II-A	“HaiTun”III-A
Description	Observation class or light work-class ROV	Work-class ROV
Size	1100mm×720mm×495mm（ length×width×height）	1650mm×1270mm×890mm（ length×width×height）
Weight	110kg（without payload）	400-600kg（without payload）
Depth rating	300m	1000m
Thruster configuration	4 horizontal+4 vertical	4 horizontal+4 vertical
Forward thrust	96kgf	295kgf
Forward speed	3kt	3.5kt
Observation system	Resolution:1920×1080, light: 4000lm×3, ±90° tilt unitor P&T unit (horizontal±90°, vertical±90°)	Resolution:1920×1080, light: 4000lm×6, ±90° tilt unitor P&T unit (horizontal±90°, vertical±90°)
Power	12kW	20-40kW
Payload	12.5kg	20-50kg
Cable reel	200m manual, custom lengths are available	1500m constant tension electric winch
Accessories	Imaging sonar Mechanical scanning sonar Side scan sonar Multi-parameter water quality probe Magnetometer Doppler velocity logger Altimeter Ultra-baseline positioning system Inertial navigation system Sub-bottom profiler 2 function manipulator 5 function manipulator	Imaging sonar Mechanical scanning sonar Side scan sonar Multi-parameter water quality probe Magnetometer Doppler velocity logger Altimeter Ultra-baseline positioning system Inertial navigation system Sub-bottom profiler 2 function manipulator 5 function manipulator Pipeline tracker detection system Hydraulic skid
Deployment system		20ft control container LARS
Auto function	Auto-heading Auto-altitude Auto-depth Station-keeping	Auto-heading Auto-altitude Auto-depth Station-keeping

*The above parameters are recommended standard configuration , each product can be customized and modified according to customer requirements, and parameter changes caused by product upgrades without prior notice.
